Introduction:
RBG OLED is a 16 bit 96*64 dot matrix OLED display module with RGB color. It is based on SSD1331 module which is a single chip CMOS OLED/PLED driver with 288 segments and 64 common output, supporting up to 96 RGB * 64 dot matrix display. It use SPI for communication.
Features:
- SPI interface
- RGB Color OLED
Specification:
- Power Voltage (VCC)：3.3V
- Display Color: RGB
- Dot Matrix: 96*64
- Operating temperature: -20~70 ℃
- Dimensions: 28mm x 32mm
Wiki:
http://www.seeedstudio.com/wiki/Xadow_RGB_OLED_96x64_v1.0
Schematic pdf/jpg:
http://www.seeedstudio.com/wiki/File:Xadow_OLED.zip
Source Code:
